Wall Mount Indoor ADA Filtered Bottle Filler

Model 1210SF Hydration Station, touchless stainless steel wall-mounted, filtered Indoor ADA bottle filler with programmable features, and separated bottle resting platform from basin. FOR INDOOR USE ONLY

Spec Sheet Download

Spec Sheet

Spec Sheet French

Installation Template

Operational / Maintenance Manual

Operational / Maintenance Manual French

Installation Drawing

Installation Drawing French

Installation Template

Parts Breakdown Drawing

AutoCAD Installation Drawing

3D Revit (RFA)

MasterSpec® Files

Brochures

Limited Warranty

Limited Warranty French

Specifications

Model 1210SF indoor wall-mount ADA filtered stainless-steel bottle-filling station shall include an ASHRAE compliant, hermetically sealed refrigeration system with thermostat. Unit features a unique, modern design with 304 satin finish stainless-steel outer shell. Energy savings feature powers down refrigeration system after two hours of non-use, and will automatically start again when used. The unit can also be programmed to shut down during planned facility closures, weekends, etc. Digital LED interface keeps user appraised of programming and error codes. The 3000-gallon (11,356 L) filter with Electronic Lifecycle Control turns water off when capacity is reached. Flow will begin again when new filter is installed. Bottle filler basin drains directly to the units waste. The system includes a bottle filler auto purge every 24 hours, an instantaneous tankless water cooler for consistent cool water, and LED illuminated bottle fill area. 115 Volts, 60Hz, rated watts: 350, full load amps: 5. Dimensions: 18-3/4 x 15-11/16 x 40-3/4". (L x W x H)

Pricing Information

$1667 USD
Contact Haws Specials

Wall Mount Indoor ADA Filtered Bottle Filler

The Haws 1210SF wall-mount filtered ADA bottle filling station is the newest addition to the most comprehensive hydration offering in the industry. The modern, innovative design is tailored to meld with office spaces, universities and airports, or serve the functional needs of spaces like a school gymnasium. Sensor activated bottle filler allows for hands free operation, and intuitive LED electronic display keeps the user informed with how many plastic bottles have been saved. Fresh, always filtered water with the Electronic Lifecycle Control feature shuts water flow off when filter reaches its gallons capacity. Flow will begin again when filter is replaced.

Energy-Efficient Refrigeration Evaporator: Enhanced tankless evaporator coil using thermal mass cooling technology, with 100 percent water content flushed with every use
Hygienic hands-free sensor operated bottle filler with vandal-resistant sensor that resists scratching and water droplet fowling
Auto-purge feature automatically cycles once every 24 hours to assure a fresh water supply as well as trap integrity
LED illuminated bottle fill area
Quick 1.1 GPM fill rate (depending on incoming pressure) for bottle filler
Smart energy savings feature powers down refrigeration system after 2 hours of non-use, and will automatically start again when used
Programmable to be shut-down during planned facility closures, weekends, etc.
High traffic area ready with a 3000-gallon (11,356 L) capacity filter
Raised platform for easy bottle resting and filling
Durable, easy to clean 304 stainless-steel skin
Retrofit installation compatibility over many existing water coolers
100% lead free waterways
Galvanized steel frame
Rated for indoor use
Designed and assembled in the USA

CSA certified to comply with NSF/ANSI 42, NSF/ANSI 53, NSF/ANSI/CAN 61: Q ≤ 1, NSF/ANSI/CAN 372, ASME A112.18.1/CSA B125.1, UL 399 and CSA C22.2 No. 120. ADA compliant to ICC A117.1, CSA B651, DOJ’s 2010 ADA Standards for Accessible Design when properly installed. ASHRAE 18 compliant chilling capacity. FCC ID: 2AUAN-1200SM and IC: 25359-1200SM Electric water coolers are not recommended or designed for outdoor applications or enclosed pool areas (chlorine), and failure to heed these conditions may void warranty.
