ADA Vandal-Resistant Wall Mount Drinking Fountain

Model 1107L, wall mounted vandal-resistant, low profile barrier-free, 14 gauge satin finish stainless steel drinking fountain with 100% lead free waterways.

Spec Sheet Download

Technical Downloads

Spec Sheet

Installation Drawing

Parts Breakdown Drawing

Operational / Maintenance Manual

AutoCAD Installation Drawing

3D Revit (RFA)

MasterSpec® Files

Limited Warranty

Specifications

Model 1107L wall mounted vandal-resistant, barrier-free drinking fountain shall include a 14 gauge Type 304 Stainless Steel satin finish basin with integral 1/4" (.6 cm) thick stainless steel back plate, vandal-resistant push-button operated stainless steel valve with front-accessible cartridge, in-line strainer and flow adjustment provides 100% lead free waterways, polished chrome-plated brass vandal-resistant bubbler head, polished chrome-plated brass vandal-resistant waste strainer, vandal-resistant stainless bottom plate, and a 1-1/4" NPT concealed all cast-brass trap. Unit can be mounted to meet ADA or Child ADA specifications.

Pricing Information

$1627 USD
Contact Haws Specials

ADA Vandal-Resistant Wall Mount Drinking Fountain

The Haws 1107L barrier-free vandal-resistant low profile drinking fountain uses a patented stainless steel, push-button activated, valve assembly allowing for front access stream adjustment as well as cartridge and strainer access. This wall mounted fountain offers the 'only' all stainless-steel valve body that is machined out of solid bar stock, is fully serviceable through the front of the push button assembly offering access to the water control cartridge and integral water supply strainer, and has front access to the water stream height adjustment for easy maintenance without having to remove the valve.

Optional 3000 gallon water filter available (model 6480)
Only stainless steel valve body that is machined out of solid bar stock
100% lead free waterways
Vandal resistant components include bubbler, button, drain and bottom plate
14 gauge Type 304 Stainless Steel design with integral mounting plate provides a well constructed sturdy fountain
Easy maintenance with front access to valve adjustment and cartridge replacement
Beautiful satin finish resists stains and corrosion
Soft rounded corners prevent mishaps and other accidents that may occur once the fountain is installed
One-piece stamped basin with low-profile design make for an aesthetically pleasing and durable unit

Model meets all current Federal Regulations for the disabled including those in the Americans with Disabilities Act. Haws manufactures drinking fountains, faucets and electric water coolers to be lead-free by all known definitions including NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and 116876 (AB 100) "NSF/ANSI/CAN 61: Q ≤ 1".
